Properties that change their look for holidays, events or team colors usually end up swapping gels or lamps by hand. The CLS LL36R is a 10 watt PAR36 LED with RGB color plus a dedicated white chip, controlled from a phone through the Tuya app, so a facade can move from warm white to red and green without a ladder.
Do I need separate controller hardware for the color effects?
No. Color, dimming and scenes are handled in the app. Bluetooth covers local control when you are on site, and Wi-Fi gives remote access to the lamps.
How bright is white compared with the colors?
On white, CLS lists about 486 lumens at 12.1 VA. Saturated colors put out far less visible light: roughly 232 lumens on green, 94 on red and 38.5 on blue. Plan color scenes for closer, smaller targets, or add fixtures on a facade when a deep blue has to read from the street.
Which fixtures can run a PAR36 smart lamp?
Any PAR36 fixture rated for the lamp, including many in-ground wells and flood lights. The die-cast aluminum body is sealed to IP67, the lamp is offered in 20, 38 or 60 degree beams, chosen when ordering, and it runs on 12 volts AC.
Specifications
| CLS part number | LL36R |
|---|---|
| Lamp type | PAR36 |
| Wattage | 10W |
| Color | RGB plus white (RGBWW) |
| Control | Tuya app via Bluetooth or Wi-Fi |
| Lumens (±10%) | White 486, Green 232, Red 94.4, Blue 38.5 |
| Power consumption | White 12.1 VA, Red 5.7 VA, Green 5.3 VA, Blue 4.3 VA |
| Beam angle | 20°, 38° or 60° (chosen when ordering) |
| Input voltage | 12V AC |
| Housing | Die-cast aluminum |
| IP rating | IP67 |
| Operating temperature | -13°F to 104°F (-25°C to 40°C) |
| Rated life (L70) | 50,000 hours |
Specifications are published by CLS Outdoor Environments and are subject to change without notice. Confirm critical dimensions and ratings with LED Spot before ordering.
Explore more smart and color LED light sources, then total the VA on each run with the low voltage wire calculator.
