CLS TFP200 Economy Series EI Core Landscape Transformer (200W)

A modest residential layout or a single commercial entry bed rarely calls for a large stainless transformer. The CLS TFP200 is a 200 watt EI core unit in a flame-retardant polycarbonate housing, with 12 and 15 volt output taps, two common terminals, and a photocell and mechanical timer built in.

How many fixtures can a 200 watt transformer carry?

Total the wattage of every lamp you plan to connect and leave a margin, planning around 160 watts of connected load on a 200 watt unit. Low wattage LED lamps let that budget stretch across a good number of fixtures, but confirm the actual total instead of estimating.

When should a run go on the 15 volt tap?

Shorter runs generally sit on the 12 volt tap, while longer runs move to 15 volts so the far fixtures still see enough voltage. Check each run for length and load before choosing a tap.

EI core or toroidal for this project?

The Economy Series EI core design suits smaller systems with simple tap needs. For larger loads, a wider tap range and a stainless enclosure, a toroidal model is the step up. The TFP200 includes overload protection with an automatic reset circuit breaker.

Specifications

Specifications are published by CLS Outdoor Environments and are subject to change without notice. Confirm critical dimensions and ratings with LED Spot before ordering.

Compare capacities across our landscape lighting transformers, and size each run with the low voltage wire calculator.
